Paccar Fuel Oil & Water Separator Filters Bundle 2277129 1922496 2234788

PACCAR MX Filter Maintenance Bundle
Genuine OEM Fuel, Oil & Water Separator Filters for MX-11/MX-13 Engines

Keep your PACCAR MX engines running strong with this complete filter maintenance bundle, featuring genuine OEM replacement filters. The combo includes a fuel filter, oil filter, and water separator — all designed for superior protection, flow efficiency, and engine performance in heavy-duty applications.

What's Included:

• Paccar 2277129 – Fuel Filter
• Paccar 1922496 – Oil Filter
• Paccar 2234788 – Water Separator Filter

Ideal for scheduled service on trucks with PACCAR MX-11 and MX-13 engines.

Key Features:

• 100% Genuine PACCAR filters, built to factory spec
• Superior filtration for fuel, oil, and water removal
• Optimized for high-mileage and extreme-duty diesel use
• Reduces wear and maximizes engine life
• Direct OEM fit, no modifications needed
• Trusted by fleet owners and independent operators

Vehicle Compatibility:
Designed for Kenworth and Peterbilt trucks with PACCAR MX-11 or MX-13 diesel engines.

Confirm filter numbers with your engine serial or maintenance manual.

Cross Reference (OEM Only):
2277129 = Fuel Filter | 1922496 = Engine Oil Filter | 2234788 = Fuel Water Separator

Shipping: Ships in 1–2 business days, securely packaged, tracked delivery.

One bundle. Full protection. Built for uptime.

❓ Quick FAQ

Which trucks/engines does this fit?
Peterbilt and Kenworth trucks powered by PACCAR MX-11 and MX-13 turbo diesel engines.

Where does each filter go?

• Oil Filter (1922496): Oil module housing, passenger side — traps soot and metal wear particles.
• Fuel Filter (2277129): Fuel module, driver's side — fine particulate filtration before the high-pressure rail.
• Water Separator (2234788): Also in the driver's side fuel module — coalesces water and larger debris from incoming fuel.

How do I service all three filters?

1. Drain the oil module, remove the cap (36mm socket), swap the oil filter cartridge and O-ring, then torque to 40 Nm.
2. Drain both fuel filters, remove their caps (36mm socket), and lift out the old cartridges.
3. Install new O-rings and filter elements, then torque the caps to 25 Nm.
4. Manually prime the system using the hand primer pump until resistance builds.
5. Cycle the ignition to RUN (without cranking) twice to purge remaining air, then start the engine and check for leaks.
